Model |
S230F |
S121F |
S121FAP |
Size |
Width:520mm Depth:770mm Height:969mm |
Width:530mm Depth:890mm Height:980mm |
Width:530mm Depth:890mm Height:980mm |
Weight |
168Kg |
168Kg |
246Kg |
Spreading Heat Way |
Air Cooling or Water Cooling |
Air Cooling or Water Cooling |
Air Cooling or Water Cooling |
Voltage Type |
220V-50Hz |
380V-50Hz |
380V-50Hz |
Rated Power |
3KW |
3.5KW |
3.5KW |
Hopper |
9.5L*2 |
9.5L*2 |
9.5L*2 |
Cylinder Capacity |
1.6L*2 |
2.0L*2 |
2.0L*2 |
Expansion System |
Gravity |
Gravity |
Pump |
Expansion Rate |
20~30% |
20~30% |
35~65% |
Time For First Cylinder |
8~10 min |
8~10 min |
8~9 min |
Production capacity(80g/cup)/H |
300 cups |
450 cups |
550 cups |
Continious Discharging Ability(80g/cup) |
>=15 cups(Single Cylinder) |
>=20 cups(Single Cylinder) |
>=25 cups(Single Cylinder) |
Standby Function |
√ |
√ |
√ |
Defrosting Function |
× |
√ |
√ |
Heating Function |
× |
√ |
√ |
Pasteurization Function |
× |
× |
√ |
